Name of Building: Steel Structure Workshop
Structure System: Steel Structure Building
Constuction Site: Algeria
1. Spec.: 105m*24m*11m
2. Primary Steel Structure included Crane Beam: H section steel with anti-rusting painting, which will be bolted together at site
3. Secondary Steel Framing: C Purlin, Tie Bar, Roof & Wall Support are fomring secondary steel framing
4. Bracing Bar: Round Steel φ12 is supplied with knee bracing and other supporting parts, whic will improve the stability and durability of the whole structural building
5. Roof Panel: EPS Insulated Steel Sandwich Panel, Thickness=50mm
6. Wall Panel: EPS Sandwich Panel, Thickness=50mm
7. Window: Plastic Steel Window
8. Door: Sliding Door with canopy
9. Brick Wall: 2m height
10. Lifting Capacity of Crane: 5T; 2 sets
11. Snow Load: 0.2KN/M2; Wind Load: 0.5KN/M2
Primary Framing Elements-columns, beams and all primary members are made by H section steels- hot rolled section steel/ welded section steel, which will be bolted together at site. A factory primer and facing paintings are applied to get better anti-rusting effect of primary framing elements.
Secondary Framing-Purlin, Tie Bar, Roof and Wall Support are formed as secondary framing
Round steel is supplied with knee bracing and other supporting parts that need portal framing, which will improve the stability and durability of the whole structural building.
Roof and Wall are covering of color-coated corrugated steel sheet or steel sandwich panel, hot dipped with zinc and aluminum compound, that is fixed to the outside of structural building to protect it against bad weather or to make it look more attractive and last for generations.
Windows and Doors
Windows: Plastic Steel Window/Aluminum-alloy Window
Door: Sliding Door/Rolling Door
Gutter, Downpipe, Transparent sheet, Ventilator and Bridge Crane will be fitted according to client's requirements
1) Light weight
2) Manifold disquisition and oversea used approving more than 40 years
3) Through especial coated dispose, the color coated steel panel's guaranty is 10-15 years, and the panel's life express 35 years by painting the antisepsis
Material after each 10 years
4) Pressing steel panel with the clear line, and many colors for choice, suitable for Any different building style materials, achieving satisfying effects
5) Pressing steel panel can be freely incised, it can satisfy the especially designing Demands.
|steel structure frame||light steel structure|
|roof and wall material||EPS sandwich panel. fiberglass sandwich panel, rock wool sandwich panel|
|sandwich panel thickness||between 50-100mm|
|material of door||sandwich panel door or security door|
|material of window||plastic steel window or aluminium allow edge window|
|Packing||directly loaded into 40ft GP, 40ft HQ, 40ft OT|
|features||1. Easy to assemble and disassemble for several times without damage|
2. Cost saving and transportation convenient
3. Anti-rust and normally more than 30 years using life
4. Quick installation, easy disassembly and moving.
|type and size||professional engineer can according your require to make any change of this house, also we can OEM|
|Our Princle: Good quality, Good service, beautiful design|
